EntelliGuard TU Trip Units: UL/ANSI Models DEH-4567B
Appendix C: Modbus Register Map
88 ©2012 General Electric All Rights Reserved
Table C-3: Commands
Register
Address
Modicon
Address Parameter Values
Implemented
Set Get
103 104 Save Real Time Clock Registers Yes NA
104 105 Read Real Time Clock Registers Yes NA
105 106 Save EPROM Data Yes NA
107 108 Upload to BIM Yes NA
108 109 Trip Breaker 0 - Reset
1 - Trip
Yes Yes
110 111 Profibus Status 0 - Disable
1 - Enable
Yes Yes
111 112 Fan State / Command Close Coil
C/D: Fan state
EntelliGuard G: activate CCC Module 0 - Off
1 - On
Yes Yes
112 113 Relay 1 state 0 - Off
1 - On
Yes Yes
113 114 Relay 2 state 0 - Off
1 - On
Yes Yes
114 115 Relay 3 state 0 - Off
1 - On
Yes Yes
115 116 Relay 4 state 0 - Off
1 - On
Yes Yes
116 117 Clear All Events Yes NA
117 118 Clear EEPROM Yes NA
118 119 Clear Energy Total Yes NA
119 120 Clear All Trip Counters Yes NA
120 121 Clear LT Trip Counter Yes NA
121 122 Clear All Pickup Counters Yes NA
122 123 Clear Short Time Trip Count Yes NA
123 124 Clear Instantaneous Trip Count Yes NA
124 125 Clear Ground Sum and CT Fault Trip Counts Yes NA
126 127 Clear Power Reversal Trip Count Yes NA
127 128 Clear Voltage Unbalance Trip Count Yes NA
128 129 Clear Under Voltage Trip Count Yes NA
129 130 Clear Current unbalance Trip Count Yes NA
130 131 Clear Overvoltage trip Count Yes NA
131 132 Clear Undervoltage Release 1 Trip Count Yes NA
132 133 Clear Undervoltage Release 2 Trip Count Yes NA
133 134 Clear Shunt 1 Trip Count Yes NA
134 135 Clear Shunt 2 Trip Count Yes NA
143 144 Trigger Waveform Capture Yes NA
144 145 Clear Waveform Capture Data Buffer Yes NA
145 146 Clear Error Counter
Same as 116. Will clear Event Log also
Yes NA
