DEH-4567B EntelliGuard TU Trip Units: UL/ANSI Models
Appendix C: Modbus Register Map
©2012 General Electric All Rights Reserved 83
Register
Address
Modicon
Address Description Range
49 30050 Power Reactive Phase A - Hi 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
50 30051 Power Reactive Phase B - Lo 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
51 30052 Power Reactive Phase B - Hi 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
52 30053 Power Reactive Phase C - Lo 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
53 30054 Power Reactive Phase C - Hi 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
54 30055 Power Reactive Phase Total - Lo 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
55 30056 Power Reactive Phase Total - Hi 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
56 30057 Power Apparent Phase A - Lo 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
57 30058 Power Apparent Phase A - Hi 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
58 30059 Power Apparent Phase B - Lo 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
59 30060 Power Apparent Phase B - Hi 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
60 30061 Power Apparent Phase C - Lo 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
61 30062 Power Apparent Phase C - Hi 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
62 30063 Power Apparent Phase Total - Lo 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
63 30064 Power Apparent Phase Total - Hi 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
64 30065 Power Demand Total - Lo 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
65 30066 Power Demand Total - Hi 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
66 30067 Frequency Measured 16 bit
67 30068 Event 1 0 - No Event
1 - Long Time Trip
2 - Short Time Trip
3 - Instantaneous Trip
4 - Ground Fault Sum
Trip
5 - Ground Fault CT
Trip
6 - Power Reversal
Trip
7 - Voltage
Unbalance Trip
8 - Under Voltage
Trip
9 - Current
unbalance trip
10 - Overvoltage trip
11 - Undervoltage
Release 1 Trip
12 - Undervoltage
Release 2 Trip
13 - Shunt 1 Trip
14 - Shunt 2 Trip
15 - Watchdog
68 30069 Year 8 bit
69 30070 Month 8 bit
70 30071 Date 8 bit
71 30072 Hour 8 bit
72 30073 Minute 8 bit
73 30074 Second 8 bit
74 30075 Phase 8 bit
75 30076 Event Specific - Low 16 bits 16 bit
76 30077 Event Specific - Hi 16 bits 16 bit
77 30078 Event 2 0 - No Event
1 - Long Time Trip
2 - Short Time Trip
3 - Instantaneous Trip
4 - Ground Fault Sum
Trip
5 - Ground Fault CT
Trip
6 - Power Reversal
Trip
7 - Voltage
Unbalance Trip
8 - Under Voltage
Trip
9 - Current
unbalance trip
10 - Overvoltage trip
11 - Undervoltage
Release 1 Trip
12 - Undervoltage
Release 2 Trip
13 - Shunt 1 Trip
14 - Shunt 2 Trip
15 - Watchdog
78 30079 Year 8 bit
79 30080 Month 8 bit
80 30081 Date 8 bit
81 30082 Hour 8 bit
82 30083 Minute 8 bit
83 30084 Second 8 bit
84 30085 Phase 8 bit
85 30086 Event Specific - Low 16 bits 16 bit
86 30087 Event Specific - Hi 16 bits 16 bit
