GE Industrial Solutions EntelliGuard TU Trip Units User Manual
Page 95
DEH-4567B
EntelliGuard TU Trip Units: UL/ANSI Models
Appendix C: Modbus Register Map
©2012 General Electric All Rights Reserved
85
Register
Address
Modicon
Address Description
Range
117
30118
Event 6
0 - No Event
1 - Long Time Trip
2 - Short Time Trip
3 - Instantaneous Trip
4 - Ground Fault Sum
Trip
5 - Ground Fault CT
Trip
6 - Power Reversal
Trip
7 - Voltage
Unbalance Trip
8 - Under Voltage
Trip
9 - Current
unbalance trip
10 - Overvoltage trip
11 - Undervoltage
Release 1 Trip
12 - Undervoltage
Release 2 Trip
13 - Shunt 1 Trip
14 - Shunt 2 Trip
15 - Watchdog
118
30119
Year
8 bit
119
30120
Month
8 bit
120
30121
Date
8 bit
121
30122
Hour
8 bit
122
30123
Minute
8 bit
123
30124
Second
8 bit
124
30125
Phase
8 bit
125
30126
Event Specific - Low 16 bits
16 bit
126
30127
Event Specific - Hi 16 bits
16 bit
127
30128
Event 7
0 - No Event
1 - Long Time Trip
2 - Short Time Trip
3 - Instantaneous Trip
4 - Ground Fault Sum
Trip
5 - Ground Fault CT
Trip
6 - Power Reversal
Trip
7 - Voltage
Unbalance Trip
8 - Under Voltage
Trip
9 - Current
unbalance trip
10 - Overvoltage trip
11 - Undervoltage
Release 1 Trip
12 - Undervoltage
Release 2 Trip
13 - Shunt 1 Trip
14 - Shunt 2 Trip
15 - Watchdog
128
30129
Year
8 bit
129
30130
Month
8 bit
130
30131
Date
8 bit
131
30132
Hour
8 bit
132
30133
Minute
8 bit
133
30134
Second
8 bit
134
30135
Phase
8 bit
135
30136
Event Specific - Low 16 bits
16 bit
136
30137
Event Specific - Hi 16 bits
16 bit
137
30138
Event 8
0 - No Event
1 - Long Time Trip
2 - Short Time Trip
3 - Instantaneous Trip
4 - Ground Fault Sum
Trip
5 - Ground Fault CT
Trip
6 - Power Reversal
Trip
7 - Voltage
Unbalance Trip
8 - Under Voltage
Trip
9 - Current
unbalance trip
10 - Overvoltage trip
11 - Undervoltage
Release 1 Trip
12 - Undervoltage
Release 2 Trip
13 - Shunt 1 Trip
14 - Shunt 2 Trip
15 - Watchdog
138
30139
Year
8 bit
139
30140
Month
8 bit
140
30141
Date
8 bit
141
30142
Hour
8 bit
142
30143
Minute
8 bit
143
30144
Second
8 bit
144
30145
Phase
8 bit
145
30146
Event Specific - Low 16 bits
16 bit
146
30147
Event Specific - Hi 16 bits
16 bit
