EntelliGuard TU Trip Units: UL/ANSI Models DEH-4567B
Appendix B: Rating Plug Nomenclature
72 ©2012 General Electric All Rights Reserved
APPENDIX B: RATING PLUG NOMENCLATURE
Table B-1: EntelliGuard G ACB Rating Plug Nomenclature
Amperes
Type Rating CT Min.
Sensor
Max.
Sensor
GTP 100-6400 200-
6400
800-6400
1, 2, 3 4,5,6,7 8 9, 10 11, 12
Prefix SKU Code
150 GTP 0150 U 01 04
200 GTP 0200 U 02 04
225 GTP 0225 U 03 06
250 GTP 0250 U 04 07
300 GTP 0300 U 04 08
350 GTP 0350 U 04 08
400 GTP 0400 U 04 10
450 GTP 0450 U 06 12
500 GTP 0500 U 06 13
600 GTP 0600 U 06 16
630 1 GTP 0630 U 07 17
700 GTP 0700 U 08 16
750 GTP 0750 U 08 20
800 GTP 0800 U 08 20
900 GTP 0900 U 10 20
1000 GTP 1000 U 10 25
1100 GTP 1100 U 12 25
1200 GTP 1200 U 12 32
1250 1 GTP 1250 U 13 32
1500 GTP 1500 U 16 40
1600 GTP 1600 U 16 40
1900 GTP 1900 U 20 50
2000 GTP 2000 U 20 50
2200 GTP 2200 U 25 50
2400 GTP 2400 U 25 64
2500 GTP 2500 U 25 64
3000 GTP 3000 U 30 64
3200 GTP 3200 U 32 64
3600 GTP 3600 U 40 64
4000 GTP 4000 U 40 64
5000 GTP 5000 U 50 64
6000 2 GTP 6000 U 60 64
6400 1 GTP 6400 U 64 64
Universal GTP UNIV U 00 00
1. IEC only.
2. UL only.
Table B-2: Legacy Rating Plug Nomenclature
Amperes
Type Rating CT Min.
Sensor
Max.
Sensor
GTP 100-6400 200-
6400
800-6400
1, 2, 3 4,5,6,7 8 9, 10 11, 12
Prefix SKU Code
60 GTP 0060 U 01 01
80 GTP 0080 U 01 01
100 GTP 0100 U 01 03
Table B-3: ITE 4000A Sensor Akits Rating Plug
Nomenclature
Amperes
Type Rating CT Min.
Sensor
Max.
Sensor
GTP 100-6400 200-
6400
800-6400
1, 2, 3 4,5,6,7 8 9, 10 11, 12
Prefix SKU Code
1600 GTP 1600 K 40 40
2000 GTP 2000 K 40 40
3000 GTP 3000 K 40 40
4000 GTP 4000 K 40 40
