DEH-4567B EntelliGuard TU Trip Units: UL/ANSI Models
Appendix C: Modbus Register Map
©2012 General Electric All Rights Reserved 73
APPENDIX C: MODBUS REGISTER MAP
Table C-1: Public Parameters
Register
Address Modicon
Address Variable Name
Allowable Values Notes
202 40203 GACB Euro
Breaker rating 0 - Undefined
1 - 250,
2 - 280,
3 - 315,
4 - 350,
5 - 400,
6 - 450,
7 - 500,
8 - 560,
9 - 605,
10 - 610,
11 - 615,
12 - 630,
13 - 720,
14 - 768,
15 - 776,
16 - 784,
17 - 800,
18 - 900,
19 - 960,
20 - 970,
21 - 980,
22 - 1000, 23 - 1125,
24 - 1196,
25 - 1210,
26 - 1225,
27 - 1250,
28 - 1280,
29 - 1440,
30 - 1536,
31 - 1552,
32 - 1568,
33 - 1600,
34 - 1800,
35 - 1920,
36 - 1940,
37 - 1960,
38 - 2000,
39 - 2250,
40 - 2400,
41 - 2425,
42 - 2450,
43 - 2500,
44 - 2560,
45 - 2880,
46 - 3072,
47 - 3104,
48 - 3136,
49 - 3200,
50 - 3840,
51 - 3880,
52 - 3920,
53 - 4000,
54 - 4800,
55 - 4850,
56 - 4900,
57 - 5000,
58 - 6144,
59 - 6208,
60 - 6272,
61 - 6400,
62 - 160,
63 - 180,
64 - 380,
65 - 385,
66 - 390
203 40204 Flash Data
Version 8 bit
205 40206 Delt/Wye System 0 - Wye
1 - Delta
206 40207 Neutral Pole
Construction 0 - OFF
1 - 50% 2 - 63%
3 - 100%
207 40208 ZSI Combination 0
1 - GF
2 - GF&ST
3- ST
4- Instantaneous
5 - GF & Inst 6 - ST & Inst
7 - GF & ST & Inst
208 40209 PT Primary
Voltage 120 - 600
209 40210 PT Connection 0 - Ph-N
1 - Ph-Ph
210 40211 Password
Protection 0 to 20
16 - Lock 19 - Unlock
211 40212 Modbus Slave
Address 8 bit value
212 40213 Profibus Slave
Address 8 bit value
213 40214 Communication
Setting 0 - 300-8N2
1 - 600-8N2
2 - 1200-8N2
3 - 2400-8N2
4 - 4800-8N2
5 - 9600-8N2
6 - 19200-8N2
7 - 300-8O1
8 - 600-8O1
9 - 1200-8O1 10 - 2400-8O1
11 - 4800-8O1
12 - 9600-8O1
13 - 19200-8O1
14 - 300-8E1
15 - 600-8E1
16 - 1200-8E1
17 - 2400-8E1
18 - 4800-8E1 19 - 9600-8E1
20 - 19200-8E1
21 - // 300-8N1
22 - // 600-8N1
23 - // 1200-8N1
24 - // 2400-8N1
25 - // 4800-8N1
26 - // 9600-8N1
27 - // 19200-8N1
