DEH-4567B EntelliGuard TU Trip Units: UL/ANSI Models
Appendix C: Modbus Register Map
©2012 General Electric All Rights Reserved 75
Register
Address
Modicon
Address Variable Name Allowable Values Notes
227 40228 GF CT Trip Pickup 1- 0.10
2- 0.11
3- 0.12
4- 0.13
5- 0.14
6- 0.15
7- 0.16
8- 0.17
9- 0.18
10- 0.19
11 - 0.20
12- 0.21
13- 0.22
14- 0.23
15- 0.24
16- 0.25
17 - 026
....
78- 0.87
79- 0.88
80- 0.89
81- 0.90 82- 0.91
83- 0.92
84- 0.93
85- 0.94
86- 0.95
87- 0.96
88- 0.97
89- 0.98
90- 0.99
91- 1.00 LCD / MODBUS
ANY IEC
GTU 17 / 40 - 0.1 - 1.0 (IEC)
NON IEC
GTU D/C - 0.2 to 0.6 (sensor <=2000A)
GTU D/C - 0.2 – 0.37 (sensor 2500 &
3200A)
GTU D/C - 0.2 – 0.3 (sensor 4000A)
GTU D/C - 0.2 – 0.24 (sensor 5000A)
GTU D/C - 0.2 (6000 – 6400)
228 40229 GF CT Trip Delay 0 - Off
1 - Band1
2- Band2
3- Band3
4- Band4
5- Band5
6- Band6
7- Band7
8- Band8
9- Band9 10- Band10
11- Band11
12- Band12
13- Band13
14- Band14
229 40230 GF CT Trip K Value 0 - 0
1 - I 2 T 2
2 - I 2 T 4.4
3 - I 4 T 19.8
230 40231 GF CT Alarm
Pickup 1- 0.10
2- 0.11
3- 0.12
4- 0.13
5- 0.14
6- 0.15
7- 0.16
8- 0.17
9- 0.18
10- 0.19
11 - 0.20 12- 0.21
13- 0.22
14- 0.23
15- 0.24
16- 0.25
17- 0.26
...
78- 0.87
79- 0.88
80- 0.89
81 - 0.90 82- 0.91
83- 0.92
84- 0.93
85- 0.94
86- 0.95
87- 0.96
88- 0.97
89- 0.98
90- 0.99
91- 1.00
231 40232 GF CT Alarm
Delay 0 - Off
1 - Band1
2- Band2
3- Band3
4- Band4 5- Band5
6- Band6
7- Band7
8- Band8
9- Band9 10- Band10
11- Band11
12- Band12
13- Band13
14- Band14 Band 1 for GACB only
232 40233 GF CT Alarm K
Value 0 - 0
1 - I
2 T 2
2 - I 2 T 4.4
3 - I 4 T 19.8
233 40234 GF Sum Trip
Pickup 1- 0.10
2- 0.11
3- 0.12
4- 0.13
5- 0.14
6- 0.15
7- 0.16
8- 0.17
9- 0.18
10- 0.19
11 - 0.20 12- 0.21
13- 0.22
14- 0.23
15- 0.24
16- 0.25
17 - 0.26
....
78- 0.87
79- 0.88
80- 0.89
81 - 0.90 82- 0.91
83- 0.92
84- 0.93
85- 0.94
86- 0.95
87- 0.96
88- 0.97
89- 0.98
90- 0.99
91- 1.00 LCD / MODBUS
ANY IEC
GTU 17 / 40 - 0.1 - 1.0 (IEC)
NON IEC
GTU D/C - 0.2 to 0.6 (sensor <=2000A)
GTU D/C - 0.2 – 0.37 (sensor 2500 &
3200A)
GTU D/C - 0.2 – 0.3 (sensor 4000A)
GTU D/C - 0.2 – 0.24 (sensor 5000A)
GTU D/C - 0.2 (6000 – 6400)
234 40235 GF SumTrip Delay 0 - Off
1- Band1
2- Band2
3- Band3
4- Band4
5- Band5
6- Band6
7- Band7
8- Band8
9- Band9 10- Band10
11- Band11
12- Band12
13- Band13
14- Band14 Band 1 for GACB only
235 40236 GF Sum K Value 0 - 0
1 - I 2 T 2
2 - I 2 T 4.4
3 - I 4 T 19.8
