EntelliGuard TU Trip Units: UL/ANSI Models
DEH-4567B
Appendix A: GTU Nomenclature
70
©2012 General Electric All Rights Reserved
Table A-18: OC and GF Protection Packages Digits 6 & 7,
WavePro when Used in UL891 Switchboards with 5 Cycle
Withstand Busing
Code Explanation
LP
LSI (S, switchable) (I, Non-switchable, used for
WavePro in Switchboards)
LQ
LSIG (S, switchable) (I, Non-switchable, used for
WavePro in Switchboards)
LR
LSIGA (S, switchable) (I, Non-switchable, used
for WavePro in Switchboards)
LS
LSIGDA* (S, G, A all switchable) (I, Non-
switchable, used for WavePro in Switchboards)
JP
Replaced by LP
JQ
Replaced by LQ
JR
Replaced by LR
JS
Replaced by LS
Table A-19: AKR, Conv. Kits with OC Protection Digits
6 & 7
Code Explanation
L3
LSI (S, switchable) (I, switchable)
L4
LSIG (S, switchable) (I, switchable)
L5
LSIGA (S, switchable) (I, switchable)
L8
LSIGDA* (S, G, A all switchable) (I, switchable)
J3
Replaced by L3
J4
Replaced by L4
J5
Replaced by L5
J8
Replaced by L8
Table A-20: PowerBreak I & II Digits 6 & 7
Code Explanation
L3
LSI (S, switchable) (I, Non-switchable)
L4
LSIG (S, switchable) (I, Non-switchable)
L5
LSIGA (S, switchable) (I, Non-switchable)
L8
LSIGDA* (S, G, A all switchable) (I, Non-
switchable)
J3
Replaced by L3
J4
Replaced by L4
J5
Replaced by L5
J8
Replaced by L8
Table A-21: EntelliGuard G ANSI and UL Low-cost ACB
Digits 6 & 7
Code Explanation
L3
LSI (S, switchable) (I, switchable ANSI only) (I is
non-switchable for AKR30S conversion kits)
L4
LSIG (S, switchable) (I, switchable ANSI only) (I is
non-switchable for AKR30S conversion kits)
L5
LSIGA (S, switchable) (I, switchable ANSI only)
L6
LSIC (S, switchable) (I, switchable ANSI only)
L7
LSICA (S, switchable) (I, switchable ANSI only)
J3
Replaced by L3
J4
Replaced by L4
J5
Replaced by L5
J6
Replaced by L6
J7
Replaced by L7
Table A-22: CVCB MTU IEC Medium Voltage OC Protection
Digits 6 & 7
Code Explanation
C1
KS (both non-switchable)
C2
KSG (all non-switchable)
C3
KSHG (K, S, G (all not switchable), H (switchable)
C4
KSHGCD (K, S, H, G and C (all switchable)
C5
KSHGCDA (K, S, H, G, C and A (all switchable)
Table A-23: Zone Selective Interlocking Digit 8
EntelliGuard G
ANSI/UL
EntelliGuard G
IEC
Power Break
I & II
WavePro, AKR,
Conv Kits
EntelliGuard
MTU
Z = ZSI, Short time and GF; user
selectable
Z
Z
Z
Z
X
T = Z + IOC ZSI; user selectable
T
T
X
T
V = RESERVED
X
X
X
W = RESERVED
X =NONE SELECTED
