GE Industrial Solutions EntelliGuard TU Trip Units User Manual

Page 87

DEH-4567B

EntelliGuard TU Trip Units: UL/ANSI Models

Appendix C: Modbus Register Map

Register

Address

Modicon

Address Variable Name

Allowable Values

Notes

259

40260

Over Voltage
Delay

0 - Off
1- 1
2- 2
3- 3
4- 4
5- 5

6- 6
7- 7
8- 8
9- 9
10- 10

11- 11
12- 12
13- 13
14 - 14
15 - 15

260

40261

Under Voltage
Pickup

1- 50
2- 51
3-52
4- 53
5-54
6- 55
7-56
8- 57
9- 58
10- 59
11 - 60
12- 61
13- 62
14- 63

15- 64
16- 65
17- 66
18- 67
19- 68
20-69
21- 70
22- 71
23-72
24- 73
25-74
26- 75
27-76
28- 77

29- 78
30- 79
31 – 80
32- 81
33- 82
34- 83
35- 84
36- 85
37- 86
38- 87
39- 88
40-89
41- 90

261

40262

Under Voltage
Delay

0 – Off
1- 1
2- 2
3- 3
4- 4
5- 5

6- 6
7- 7
8- 8
9- 9
10- 10

11- 11
12- 12
13- 13
14 - 14
15 - 15 C22

262

40263

Under Voltage
Zero-Volt Trip
Enable

0 - Disable
1 – Enable

263

40264

Voltage
Unbalance Pickup

1- 10
2- 11
3-12
4- 13
5-14
6- 15
7-16
8- 17
9- 18
10- 19
11 - 20
12- 21
13- 22
14- 23

15- 24
16- 25
17- 26
18- 27
19- 28
20-29
21- 30
22- 31
23-32
24- 33
25-34
26- 35
27-36
28- 37

29- 38
30- 39
31 - 40
32- 41
33- 42
34- 43
35- 44
36- 45
37- 46
38- 47
39- 48
40-49
41- 50

264

40265

Voltage
Unbalance Delay

0 - Off
1- 1
2- 2
3- 3
4- 4
5- 5

6- 6
7- 7
8- 8
9- 9
10- 10

11- 11
12- 12
13- 13
14-14
15-15
