EntelliGuard TU Trip Units: UL/ANSI Models
DEH-4567B
Appendix C: Modbus Register Map
76
©2012 General Electric All Rights Reserved
Register
Address
Modicon
Address Variable Name
Allowable Values
Notes
236
40237
GF Sum Alarm
Pickup
1- 0.10
2- 0.11
3- 0.12
4- 0.13
5- 0.14
6- 0.15
7- 0.16
8- 0.17
9- 0.18
10- 0.19
11 - 0.20
12- 0.21
13- 0.22
14- 0.23
15- 0.24
16- 0.25
17- 0.26
...
78- 0.87
79- 0.88
80- 0.89
81 - 0.90
82- 0.91
83- 0.92
84- 0.93
85- 0.94
86- 0.95
87- 0.96
88- 0.97
89- 0.98
90- 0.99
91- 1.00
LCD / MODBUS
ANY IEC
GTU 17 / 40 - 0.1 - 1.0 (IEC)
NON IEC
GTU D/C - 0.2 to 0.6 (sensor <=2000A)
GTU D/C - 0.2 – 0.37 (sensor 2500 &
3200A)
GTU D/C - 0.2 – 0.3 (sensor 4000A)
GTU D/C - 0.2 – 0.24 (sensor 5000A)
GTU D/C - 0.2 (6000 – 6400)
237
40238
GF Sum Alarm
Delay
0 - Off
1 - Band1
2- Band2
3- Band3
4- Band4
5- Band5
6- Band6
7- Band7
8- Band8
9- Band9
10- Band10
11- Band11
12- Band12
13- Band13
14- Band14
Band 1 for GACB only
238
40239
GF Sum Alarm K
Value
0 - 0
1 - I
2
T 2
2 - I
2
T 4.4
3 - I
4
T 19.8
239
40240
UEF Pickup
1- 0.10
2- 0.11
3- 0.12
....
89- 0.98
90- 0.99
91- 1.00
1 (0.1) only available with Aux Power
240
40241
UEF Delay
0 - Off
1- Band1
2- Band2
3- Band3
4- Band4
5- Band5
6- Band6
7- Band7
8- Band8
9- Band9
10- Band10
11- Band11
12- Band12
13- Band13
14- Band14
When UEF is used in combination with
REF, SEF, or SEF and REF, it cannot be
switched OFF
241
40242
UEF K
0 - 0
1 - I
2
T 2
2 - I
2
T 4.4
3 - I
4
T 19.8
242
40243
SEF Pickup
1- 0.10
2- 0.11
3- 0.12
....
89- 0.98
90- 0.99
91- 1.00
1 (0.1) only available with Aux Power.
The SEF Pickup must be greater than
UEF Pickup Setting.
243
40244
SEF Delay
0 - Off
1- Band1
2- Band2
3- Band3
4- Band4
5- Band5
6- Band6
7- Band7
8- Band8
9- Band9
10- Band10
11- Band11
12- Band12
13- Band13
14- Band14
The SEF Delay must be at least 0.1
second greater than UEF delay setting
244
40245
SEF K
0 - 0
1 - I
2
T 2
2 - I
2
T 4.4
3 - I
4
T 19.8
245
40246
REF Pickup
1- 0.10
2- 0.11
3- 0.12
....
89- 0.98
90- 0.99
91- 1.00
1 (0.1) only available with Aux Power
246
40247
REF Delay
0 - OFF
1 - Fixed 130ms delay
247
40248
Timeout Metering 0 - No
1 – Yes
If lcd screen is left at Metering, will go to
Home Menu after 5 minutes
258
40259
Over Voltage
Pickup
1- 110
2- 111
3-112
4- 113
5-114
6- 115
7-116
8- 117
9- 118
10- 119
11 - 120
12- 121
13- 122
14- 123
15- 124
16- 125
17- 126
18- 127
19- 128
20-129
21- 130
22- 131
23-132
24- 133
25-134
26- 135
27-136
28- 137
29- 138
30- 139
31 - 140
32- 141
33- 142
34- 143
35- 144
36- 145
37- 146
38- 147
39- 148
40-149
41- 150
