EntelliGuard TU Trip Units: UL/ANSI Models DEH-4567B
Appendix A: GTU Nomenclature
68 ©2012 General Electric All Rights Reserved
Table A-11: OC and GF Protection Packages Col. 6 & 7
EntelliGuard G ANSI/UL OC Protection
Code Explanation
L1
RESERVED
L2 RESERVED
L3 LSI (S, switchable) (I, switchable ANSI only) (I is
non-switchable for AKR30S conversion kits)
L4 LSIG (S, switchable) (I, switchable ANSI only) (I is
non-switchable for AKR30S conversion kits)
L5 LSIGA (S, switchable) (I, switchable ANSI only)
L6 LSIC (S, switchable) (I, switchable ANSI only)
L7 LSICA (S, switchable) (I, switchable ANSI only)
L8 LSIGDA* (S, G, A all switchable) (I, switchable
ANSI only)
L9 LSIGCDA* (S, G, C, A all switchable) (I, switchable
ANSI only)
LA RESERVED
LB RESERVED
LC LSH (S, switchable) (H, switchable ANSI only) (H
fixed in AKR30S conversion kits)
LD LSHG (S, switchable) (H, switchable ANSI only) (
H fixed in AKR30S Conversion Kits)
LE LSHGA (S, switchable) (H, switchable ANSI only)
LF LSHC (S, switchable) (H, switchable ANSI only)
LG LSHCA (S, switchable) (H, switchable ANSI only)
LH LSHGDA* (S, G, A all switchable) (H, switchable
ANSI only)
LK LSHGCDA* (S, G, C, A all switchable) (H,
switchable ANSI only)
LM RESERVED
LN RESERVED
LP LSI (S, switchable) (I, Non-switchable, used for
WavePro in Switchboards)
LQ LSIG (S, switchable) (I, Non-switchable, used for
WavePro in Switchboards)
LR LSIGA (S, switchable) (I, Non-switchable, used
for WavePro in Switchboards)
LS LSIGDA* (S, G, A all switchable) (I, Non-
switchable, used for WavePro in Switchboards)
LT RESERVED
LU RESERVED
LV RESERVED
LW G (PB II Switch and EntelliGuard Switch GF Relay
only)
LY GA (PB II Switch and EntelliGuard Switch GF
Relay only)
LZ All Protection Disabled (Entellisys only)
Table A-12: OC and GF Protection Packages Digits 6 & 7
EntelliGuard G ANSI/UL OC Protection with Fuse Settings
Code Explanation
J1
RESERVED
J2 RESERVED
J3 Replaced by L3
J4 Replaced by L4
J5 Replaced by L5
J6 Replaced by L6
J7 Replaced by L7
J8 Replaced by L8
J9 Replaced by L9
JA RESERVED
JB RESERVED
JC Replaced by LC
JD Replaced by LD
JE Replaced by LE
JF Replaced by LF
JG Replaced by LG
JH Replaced by LH
JK Replaced by LK
JM RESERVED
JN RESERVED
JP Replaced by LP
JQ Replaced by LQ
JR Replaced by LR
JS Replaced by LS
JT RESERVED
JU RESERVED
JV RESERVED
JW RESERVED
JY RESERVED
Table A-13: OC and GF Protection Packages Digits 6 & 7,
EntelliGuard G IEC Series OC Protection
Code Explanation
K1
LS (both non-switchable)
K2 LSG (all non-switchable)
K3 LSIG (L, S, G, (all not switchable), I (switchable)
K4 LSHG (L, S, G (all not switchable), H (switchable)
K5 LSIGCD (L , S, I, G and C (all switchable)
K6 LSIGCDA (L, S, I, G, C and A (all switchable)
K7 LSHGCD (L, S, H, G and C (all switchable)
K8 LSHGCDA (L, S, H, G, C and A (all switchable)
K9 LSI (L, S (not switchable, I (switchable)
KA NONE - All protections disabled
KE LSIED (L , S, I, E - only L, S, & I are switchable)
KG LSHED (L, S, H, E - only L, S, and H are
switchable)
