EntelliGuard TU Trip Units: UL/ANSI Models

DEH-4567B

Appendix C: Modbus Register Map

Register

Address

Modicon

Address Variable Name

Allowable Values

Notes

215

40216

Long Time Trip
Pickup

1 - 0.5
2- 0.55
3- 0.6
4- 0.65
5- 0.7

6-0.75
7-0.8
8-0.85
9 - 9
10 -9.5

11 - 1.0
12 - 0.4 (Model 17
and 40 only)
13 - 0.45 (Model
17 and 40 only)

216

40217

Long Time Trip
Delay

0 - Off
1- Band1

2- Band2

Max 44 with I

Max 22 without I

217

40218

Long Time
Cooling Constant

0 - goes to 0
1 - 12 min.
cooling

219

40220

Protective Relay
Trip Enable

0 - OFF
1 - ON

220

40221

Frequency

0 - 50Hz

1 - 60Hz

2 - 400Hz

221

40222

Earth Fault Type 0 - Off

1 - UEF
2 - UEF + REF

3 - UEF + SEF
4 - REF + SEF

5 - UEF + REF +
SEF

222

40223

Short Time Trip
Pickup

1 - 1.5
2- 2.0
3- 2.5
4- 3.0
5- 3.5
6- 4.0
7- 4.5
8- 5.0

9- 5.5
10- 6.0
11- 6.5
12 - 7.0
13- 7.5
14- 8.0
15- 8.5

16- 9.0
17- 9.5
18- 10
19 - 10.5
20 - 11
21 - 11.5
22 - 12

223

40224

Short Time Trip
Delay

0 - Off
1- Band1
2- Band2
3- Band3
4- Band4
5- Band5

6- Band6
7- Band7
8- Band8
9- Band9
10- Band10
11- Band11

12- Band12
13- Band13
14- Band14
15 - Band 15
16 - Band 16
17 - Band 17

224

40225

Short Time Kst

0 - 0
1 - 2

2 - 8
3 - 18

225

40226

Instantane-
ous Trip Pickup

0- Off (For
switchable Inst
only)
1- Invalid
2- 2
3- 2.5
4- 3
5- 3.5
6- 4
7- 4.5
8- 5
9- 5.5
10- 6
11- 6.5
12- 7
13- 7.5

14- 8
15- 8.5
16- 9
17- 9.5
18- 10
19- 10.5
20- 11
21- 11.5
22- 12
23- 12.5
24- 13
25- 13.5
26- 14
27- 14.5
28- 15
29- 16

30- 17
31- 18
32- 19
33- 20
34- 21
35- 22
36- 23
37- 24
38- 25
39- 26
40- 27
41- 28
42- 29
43- 30

226

40227

Reduced
Instantane-
ous Trip Pickup

1- 1.5
2- 2
3- 2.5
4- 3
5- 3.5
6- 4
7- 4.5
8- 5
9- 5.5
10- 6

11- 6.5
12- 7
13- 7.5
14- 8
15- 8.5
16- 9
17- 9.5
18- 10
19- 10.5
20- 11

21- 11.5
22- 12
23- 12.5
24- 13
25- 13.5
26- 14
27- 14.5
28- 15
