DEH-4567B EntelliGuard TU Trip Units: UL/ANSI Models
Appendix A: GTU Nomenclature
©2012 General Electric All Rights Reserved 69
Table A-14: OC and GF Protection Packages Digits 6 & 7,
EntelliGuard G IEC Series OC Protection with Fuse
Settings
Code Explanation
N1
JS (both non-switchable)
N2 JSG (all non-switchable)
N3 JSIG (J, S, G, (all non-switchable), I (switchable))
N4 JSHG (J, S, G (all non-switchable), H (switchable)
N5 JSIGCD (J , S, I, G and C (all switchable)
N6 JSIGCDA (J, S, I, G, C and A (all switchable)
N7 JSHGCD (J, S, H, G and C (all switchable)
N8 JSHGCDA (J, S, H, G, C and A (all switchable)
N9 JSI (J, S (non-switchable), I (switchable)
ND JSIED (J , S, I, E - only L, S, & I are switchable)
NF JSHED (J, S, H, E - only L, S, and H are
switchable)
Table A-15: OC and GF Protection Packages Digits 6 & 7,
Mpact Series OC Protection (IEC)
Code Explanation
M1
LS (all non-switchable)
M2 LSG (all non-switchable)
M3 LSI (L ,S (non-switchable), I (switchable)
M4 LSIGCD (L, S, I, G and C (all switchable)
M5 RESERVED
M6 RESERVED
M7 RESERVED
M8 RESERVED
M9 RESERVED
MA NONE - All protections disabled
MC LSIED (L, S, I, E - only L, S, & I are switchable)
Table A-16: OC and PROTECTION Definitions: Digits 6 & 7
Code Explanation
L
Long Time Protection (L) + Fuse Settings
(Selectable I
2 T or Fuse Setting)
J Replaced by L
S Short Time (switchable if Instantaneous (I)
protection is enabled)
I Standard Range Adjustable Instantaneous,
(IOC, 2x-15x)
H High Range Adjustable Instantaneous (IOC, 2x-
30x) (Fixed 22kA for AKR30S Conversion Kits)
G Ground Fault Protection (GFP, 3-wire or 4-wire,
internal summing)
C External CT for ground fault detection (input
from external summing CTs, used for multiple
source ground fault detection)
D Makes G & C options switchable (not UL listed)
A Enable Alarm Function for Ground Fault and/or
External CT GF. Not available with E option
* Function combination is NOT UL Listed
K Long Time Inverse IEC protection curves
E UEF, REF, SEF; non switchable, no alarm
function
• Refer to EntelliGuard Trip Unit Application Guide for detailed
descriptions and configuration
Table A-17: OC and GF Protection Packages Digits 6 & 7,
WavePro
Code Explanation
L3
LSI (S, switchable) (I, switchable ANSI only (Code
1&2, WP)
L4 LSIG (S, switchable) (I, switchable ANSI only
(Code 1&2, WP)
L5 LSIGA (S, switchable) (I, switchable ANSI only
(Code 1&2, WP)
L8 LSIGDA* (S, G, A all switchable) (I, switchable
ANSI only (Code 1&2, WP)
J3 Replaced by L3
J4 Replaced by L4
J5 Replaced by L5
J8 Replaced by L8
