EntelliGuard TU Trip Units: UL/ANSI Models
DEH-4567B
Appendix C: Modbus Register Map
80
©2012 General Electric All Rights Reserved
Register
Address
Modicon
Address Variable Name
Allowable Values
Notes
297
40298
Current Alarm 1
Pickup Off
1 - 0.5
2 - 0.55
3 - 0.60
4 - 0.65
5 - 0.70
6 - 0.75
7 - 0.80
8 - 0.85
9 - 0.90
10 - 0.95
11 - 1.00
298
40299
Current Alarm 2
Pickup On
1 - 0.5
2 - 0.55
3 - 0.60
4 - 0.65
5 - 0.70
6 - 0.75
7 - 0.80
8 - 0.85
9 - 0.90
10 - 0.95
11 - 1.00
299
40300
Current Alarm 2
Pickup Off
1 - 0.5
2 - 0.55
3 - 0.60
4 - 0.65
5 - 0.70
6 - 0.75
7 - 0.80
8 - 0.85
9 - 0.90
10 - 0.95
11 - 1.00
300
40301
Bell Alarm (Bell
Alarm 1)
0 - Disabled
1 - Shunt Trip
2 - UVR Trip
3 - Over Current
Trip
4 - Protective
Relay Trip
5 - Shunt, UVR
6 - Shunt, Over
Current
7 - Shunt,
Protective Relay
8 - UVR, Over
Current
9 - UVR, Protective
Relay
10 - Over Current,
Protective Relay
11 - Shunt Trip,
UVR, Over Current
12 - Shunt, UVR,
Protective Relay
13 - Shunt, Over
Current,
Protective Relay
14 - UVR, Over
Current,
Protective Relay
15 - Shunt, UVR,
Over Current,
Protective Relay
301
40302
Bell Alarm with
lockout (Bell
Alarm 2)
0 - Disabled
1 - Shunt Trip
2 - UVR Trip
3 - Over Current
Trip
4 - Protective
Relay Trip
5 - Shunt, UVR
6 - Shunt, Over
Current
7 - Shunt,
Protective Relay
8 - UVR, Over
Current
9 - UVR, Protective
Relay
10 - Over Current,
Protective Relay
11 - Shunt Trip,
UVR, Over Current
12 - Shunt, UVR,
Protective Relay
13 - Shunt, Over
Current,
Protective Relay
14 - UVR, Over
Current,
Protective Relay
15 - Shunt, UVR,
Over Current,
Protective Relay
302
40303
ZSI Short Time
Delay Band
0 - OFF
1- Band1
2- Band2
3- Band3
4- Band4
5- Band5
6- Band6
7- Band7
8- Band8
9- Band9
10- Band10
11- Band11
12- Band12
13- Band13
14- Band14
15 - Band 15
16 - Band 16
17 - Band 17
303
40304
ZSI Short Time Kst 0 - 0
1 - 2
2 - 8
3 - 18
304
40305
ZSI GF Trip Delay 0 - OFF
1 - Band1
2- Band2
3- Band3
4- Band4
5- Band5
6- Band6
7- Band7
8- Band8
9- Band9
10- Band10
11 - Band 11
12-Band 12
13-Band13
14-Band14
305
40306
ZSI GF Trip K
Value
0 - 0
1 - I
2
T 2
2 - I
2
T 3
3 - I
4
T 18
306
40307
Breaker Position 1 - CLOSE
0 - OPEN
307
40308
Waveform Trigger
Source - Manual
0 - OFF
1 - ON
308
40309
Waveform Trigger
Source - Over
Current
0 - OFF
1 - ON
