EntelliGuard TU Trip Units: UL/ANSI Models DEH-4567B
Appendix C: Modbus Register Map
82 ©2012 General Electric All Rights Reserved
Register
Address
Modicon
Address Variable Name Allowable Values Notes
637 40638
638 40639
639 40640
Table C-2: Inputs from GTU
Register
Address
Modicon
Address Description Range
14 30015 Power Peak Demand Total - Lo 32 bits 32 bit, Scaled value: 32 bit value/10
15 30016 Power Peak Demand Total - Hi 32 bits 32 bit, Scaled value: 32 bit value/10
16 30017 GTU Rev 8 bit
17 30018 Software Rev 8 bit
18 30019 Voltage Phase A 16 bit, Scaling 1:1
19 30020 Voltage Phase B 16 bit, Scaling 1:1
20 30021 Voltage Phase C 16 bit, Scaling 1:1
21 30022 Current Phase A(LO 32 bits ) 32 bit, Scaling 1:1
22 30023 Current Phase A(HI 32 bits ) 32 bit, Scaling 1:1
23 30024 Current Phase B(LO 32 bits ) 32 bit, Scaling 1:1
24 30025 Current Phase B(HI 32 bits ) 32 bit, Scaling 1:1
25 30026 Current Phase C(LO 32 bits ) 32 bit, Scaling 1:1
26 30027 Current Phase C(HI 32 bits ) 32 bit, Scaling 1:1
27 30028 Current Phase N(LO 32 bits ) 32 bit, Scaling 1:1
28 30029 Current Phase N(HI 32 bits ) 32 bit, Scaling 1:1
29 30030 Rating Plug Value 0 - 0
1 - 150
2 - 200,
3 - 225,
4 - 250,
300,
350,
400,
450,
500,
600,
630,
700, 800,
900,
1000,
1100,
1200,
1250,
1500,
1600,
1900,
2000,
2200,
2400,
2500, 3000,
3200,
3600,
4000,
5000,
6000,
100,
750,
3500,
4500,
6400,
60,
80
31 30032 Energy Total ( 0-15 bits ) Divide value by 10 to
get kWH 64 bit, Scaled value = [(Register 35 * 2^32) + (32 bit value in
registers 31 + 32)]/10
32 30033 Energy Total (16-31 bits) Divide value by 10 to
get kWH 64 bit, Scaled value = [(Register 35 * 2^32) + (32 bit value in
registers 31 + 32)]/10
33 30034 Reserved
34 30035 Reserved
35 30036 Energy Rollover Count 16 bit, Scaled value = [(Register 35 * 2^32) + (32 bit value in
registers 31 + 32)]/10
36 30037 Power Factor Phase A 16 bit
37 30038 Power Factor Phase B 16 bit
38 30039 Power Factor Phase C 16 bit
39 30040 Power Factor Total 16 bit
40 30041 Power Real Phase A - Lo 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
41 30042 Power Real Phase A - Hi 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
42 30043 Power Real Phase B - Lo 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
43 30044 Power Real Phase B - Hi 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
44 30045 Power Real Phase C - Lo 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
45 30046 Power Real Phase C - Hi 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
46 30047 Power Real Phase Total - Lo 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
47 30048 Power Real Phase Total - Hi 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
48 30049 Power Reactive Phase A - Lo 16 bits 32 bit (Divide value by 10 to get KW) Scaled value: 32 bit value/10
