Table 93: byte 2, Relay 3 status, Relay 2 status – GE Industrial Solutions EntelliGuard TU Trip Units User Manual
Page 67: Relay 1 status, Zsi out active, Zsi in active, Gf sum pickup state, Short time pickup state, Long time pickup state, B0_7
DEH-4567B
EntelliGuard TU Trip Units: UL/ANSI Models
Profibus Communication
©2012 General Electric All Rights Reserved
57
Table 9-3: Byte 2
Relay 3
Status
Relay 2
Status
Relay 1
Status
ZSI OUT
Active
ZSI IN active
GF Sum
Pickup State
Short Time
Pickup State
Long Time
Pickup State
7
6
5
4
3
2
1
0
B0_7
B0_6
B0_5
B0_4
B0_3
B0_2
B0_1
B0_0
1
1
1
1
1
1
1
1
255
Table 9-4: Byte 3
Disconnect
Indication
Test Position
Breaker
Connected
Breaker
Closed and
Connected
Spring
Charge
Breaker
Ready to
Close
Breaker
Position
V Detect
33
32
31
30
29
28
27
26
B3_7
B3_6
B3_5
B3_4
B3_3
B3_2
B3_1
B3_0
1
1
1
1
1
1
1
1
255
Table 9-5: Byte 4
Power
Reversal
Status
Current
Unbalance
Status
Overvoltage
Status
Undervoltage
Status
Voltage
Unbalance
Status
UVR 2 Trip
Status
UVR 1 Trip
Status
Shunt 2 Trip
Status
25
24
23
22
21
18
17
16
B2_7
B2_6
B2_5
B2_4
B2_3
B2_2
B2_1
B2_0
1
1
1
1
1
1
1
1
255
Table 9-6: Byte 5
RELT Status
Current
Alarm 2
Status
Current
Alarm 1
Status
GF CT Alarm
Status
GF Sum
Alarm Status
Power
Reversal
Alarm Status
Current
Unbalance
Alarm Status
Overvoltage
Alarm Status
65
64
63
62
61
60
59
58
B5_7
B5_6
B5_5
B5_4
B5_3
B5_2
B5_1
B5_0
1
1
1
1
1
1
1
1
255
Table 9-7: Byte 6
Undervoltage
Alarm Status
Voltage
Unbalance
Alarm Status GF CT Status
WFC Data
Available
GTU Tripped Remote Close
Draw Out
Cassette
Indication
57
56
55
54
51
44
35
34
B4_7
B4_6
B4_5
B4_4
B4_3
B4_2
B4_1
B4_0
1
1
1
1
1
1
1
1
255
