DEH-4567B EntelliGuard TU Trip Units: UL/ANSI Models
Appendix C: Modbus Register Map
©2012 General Electric All Rights Reserved 81
Register
Address
Modicon
Address Variable Name Allowable Values Notes
309 40310 Waveform Trigger
Source -
Protection Relays 0 - OFF
1 - ON
310 40311 Waveform Trigger
Source - Current
Alarm 1 0 - OFF
1 - ON
311 40312 Waveform Trigger
Source - Current
Alarm 2 0 - OFF
1 - ON
312 40313 Reduced
Instantaneous Let
Through (RELT) 0 - OFF
1 - ON
600 40601 User
Programmable
600 - 619 0 - 1023 Write values of the desired Input
registers so that those Input registers
can be read in a sequence to reduce
the bus traffic
601 40602
602 40603
603 40604
604 40605
605 40606
606 40607
607 40608
608 40609
609 40610
610 40611
611 40612
612 40613
613 40614
614 40615
615 40616
616 40617
617 40618
618 40619
619 40620
620 40621 User Programm-
able 620 - 639 0 - 1023 Write values of the desired Discrete
registers so that those Input registers
can be read in a sequence to reduce
the bus traffic
621 40622
622 40623
623 40624
624 40625
625 40626
626 40627
627 40628
628 40629
629 40630
630 40631
631 40632
632 40633
633 40634
634 40635
635 40636
636 40637
