Web-Based Management

 Hybrid Link: A segment which consists of Access and Trunk links. The hybrid

port has both the features of access and trunk ports. A hybrid port has a PVID

belonging to a particular VLAN, and it also forwards the specified tagged-frames

for the purpose of VLAN communication across switches.

Note:

It’s not necessary to type ‘1’ in the tagged VID. The hybrid port will forward the

frames of VLAN 1.

The trunk port has to be connected to a trunk/hybrid port of the other switch. Both the

tagged VID of the two ports have to be the same.

 Untagged VID: This column field is available when Link Type is set as Access Link

and Hybrid Link. Assign a number in the range between 1 and 4094.

 Tagged VID: This column field is available when Link Type is set as Trunk Link and

Hybrid Link. Assign a number in the range between 1 and 4094.

 Click

Apply

to have the configuration take effect.

 You can see the link type, untagged VID, and tagged VID information of each port in

the below table.
