Web-Based Management
port. When 1
st
Ring Port fails, the system will automatically upgrade the 2
nd
Ring Port to be the working port.
Enable Couple Ring: To enable the couple ring function, tick the checkbox beside the
Enable Couple Ring string label.
Couple Port: Assign the member port which is connected to the other ring group.
Control Port: When the Enable Couple Ring checkbox is ticked, you have to
assign the control port to form a couple-ring group between the two X-rings.
Enable Dual Homing: Set up one of the ports on the switch to be the Dual Homing
port. For a switch, there is only one Dual Homing port. Dual Homing function works
only when the X-Ring function enabled.
Enable Dual Ring: When this check box is ticked, the ‗Enable Ring Master‘ check
box will then also be enabled by the system, which means this equipment is assigned
as the Ring Master. The Dual Ring differs from the Couple Ring in that it only needs a
unit to form a redundant linking system of two rings.
And then, click
Apply
to have the configuration take effect.
99
