Hardware Description
2.4 LED Indicators
LED Color Status Meaning
PWR Green
On The switch is powered on
Off No power
R.M. Green
On The switch is the master of the X-Ring
Off The switch is not the master of the X-Ring
PWR1 Green
On Power 1 is active
Off Power 1 is inactive
PWR2 Green
On Power 2 is active
Off Power 2 is inactive
FAULT Red
On Power or port failure
Off No failure, or no power applied
P9, P10
(RJ-45)
Green (Upper
LED)
On A network device is detected.
Blinking The port is transmitting or receiving data.
Off No device attached
Green (Lower
LED)
On 1000M
Off 10/100M
Link/Active
(P9, P10 SFP)
Green
On The SFP port is linking
Blinks The port is transmitting or receiving data.
Off No device attached
P1 to P8 Green On A network device is detected.
