Web-Based Management
6.14 Port Control
In Port control you can configure the settings of each port to control the connection
parameters. The status of each port is listed beneath.
 Port: Use the scroll bar and click on the port number to choose the port to be
configured.
 State: Current port state. The port can be set to disable or enable mode. If the port state
is set as ‗Disable‘, it will not receive or transmit any packet.
 Negotiation: Auto and Force. Being set as Auto, the speed and duplex mode are
negotiated automatically. When you set it as Force, you have to set the speed and
duplex mode manually.
 Speed: It is available for selecting when the Negotiation column is set as Force. When
the Negotiation column is set as Auto, this column is read-only.
 Duplex: It is available for selecting when the Negotiation column is set as Force.
When the Negotiation column is set as Auto, this column is read-only.
 Flow Control: Whether or not the receiving node sends feedback to the sending node
is determined by this item. When enabled, once the device exceeds the input data rate
of another device, the receiving device will send a PAUSE frame which halts the
transmission of the sender for a specified period of time. When disabled, the receiving
device will drop the packet if too much to process.
 Security: When the Security selection is set as ‗On‘, any access from the device which
connects to this port will be blocked unless the MAC address of the device is included
in the static MAC address table. See the segment of MAC Address Table—Static
MAC Addresses.
 Click
Apply to have the configuration take effect.
