Web-Based Management
6.13 Port Statistics
The following chart provides the current statistic information which displays the real-time
packet transfer status for each port. The user might use the information to plan and
implement the network, or check and find the problem when the collision or heavy traffic
occurs.
Port: The port number.
Type: Displays the current speed of connection to the port.
Link: The status of linking—‗Up‘ or ‗Down‘.
State: It‘s set by Port Control. When the state is disabled, the port will not transmit or
receive any packet.
Tx Good Packet: The counts of transmitting good packets via this port.
Tx Bad Packet: The counts of transmitting bad packets (including undersize [less than
64 octets], oversize, CRC Align errors, fragments and jabbers packets) via this port.
Rx Good Packet: The counts of receiving good packets via this port.
Rx Bad Packet: The counts of receiving good packets (including undersize [less than
64 octets], oversize, CRC error, fragments and jabbers) via this port.
Tx Abort Packet: The aborted packet while transmitting.
Packet Collision: The counts of collision packet.
Packet Dropped: The counts of dropped packet.
Rx Bcast Packet: The counts of broadcast packet.
Rx Mcast Packet: The counts of multicast packet.
Click
Clear
button to clean all counts.
