Introduction
Flash ROM
4Mbytes
DRAM
32Mbytes
Connector
10/100TX (PoE): 8 x RJ-45
10/100/1000T/ Mini-GBIC Combo:
2 x RJ-45 + 2 x 100/1000 SFP sockets
RS-232 connector: RJ-45 type
Network Cable
10Base-T: 2-pair UTP/STP Cat. 3 or above cable
EIA/TIA-568 100-ohm (100m)
100Base-TX: 2-pair UTP/STP Cat. 5 or above cable
EIA/TIA-568 100-ohm (100m)
1000Base-TX: 2-pair UTP/STP Cat. 5E or above cable
EIA/TIA-568 100-ohm (100m)
PoE pin assignment
RJ-45 ports 1 to 8 support IEEE 802.3af End-point, Alternative A
mode. Per port provides 15.4W ability.
Positive (VCC+): RJ-45 pin 1, 2.
Negative (VCC-): RJ-45 pin 3, 6.
Protocol
CSMA/CD
LED
Per unit: Power (Green), Power 1 (Green), Power 2 (Green), Fault
(Red), Master (Green), FWD (Green)
8 port 10/100: Link/Activity (Green), Full duplex/Collision
(Amber)
SFP port: LNK/ACT(Green), 1000T: LNK/ACT(Green),
1000M(Green)
Power Supply
External Power Supply: Redundant 48 VDC with removable
terminal block for master and slave power
Power Consumption
116Watts (Full load)
