Web-Based Management

6.15.3 State Activity

Having set up the LACP aggregator on the tab of Aggregator Setting, you can configure the

state activity for the members of the LACP trunk group. You can tick or cancel the

checkbox beside the state label. When you remove the tick mark of the port and click

Apply

, the port state activity will change to Passive.

 Active: The port automatically sends LACP protocol packets.

 Passive: The port does not automatically send LACP protocol packets, and responds

only if it receives LACP protocol packets from the opposite device.

[NOTE]

A link having two passive LACP nodes will not perform dynamic LACP

trunk because both ports are waiting for an LACP protocol packet from the
opposite device.

State Activity of Switch 1
