PNEG-707 12', 18', 24' and 30' GSI Commercial Tower Dryer 437
28. Appendix B
Hardware
Quantity of hardware varies by dryer model.
Description Uses
Galvanized
5/16" (0.79375 cm) x 3/4" (1.905 cm) Slotted Truss Head Bolt ..................................................... Cool Room Floor
5/16" (0.79375 cm) x 3/4" (1.905 cm) Whiz Lock Bolt .................................................................Inside Wall Sheets
5/16" (0.79375 cm) x 1" (2.54 cm) Whiz Lock Bolt ......................................................................Inside Wall Sheets
5/16" (0.79375 cm) Whiz Lock Nut ..............................................................................................Inside Wall Sheets
#10 x 1" (2.54 cm) Self Tapping Screw........................................................................................ Heat Section Door
and Cool Room Floor
3/8" (0.9525 cm) Washer .......................................................................................................................... Walkways
3/8" (0.9525 cm) Hex Head Nut ............................................................................................................... Walkways
3/8" (0.9525 cm) x 1" (2.54 cm) Hex Head Bolt ....................................................................................... Walkways
3/8" (0.9525 cm) x 2" (5.08 cm) Hex Head Bolt .............................................Lifting Clips to Vertical Channels and
Base Stiffeners to Vertical Channels
1/2" (1.27 cm) x 1" (2.54 cm) Hex Head Bolt ....................................................................... Outside Hopper Sheets
and Gearbox Motor to Gearbox
1/2" (1.27 cm) Hex Head Nut .............................................................................................. Outside Hopper Sheets
1/2" (1.27 cm) Washer ......................................................................................................... Outside Hopper Sheets
1/2" (1.27 cm) x 1-1/2" Grade 8, Hex Head Bolt ............................................................................... Blower Bracing
1/2" (1.27 cm) x 2-1/2" Grade 5, Hex Head Bolt ............................................................................... Base Stiffeners
5/8" (1.5875 cm) x 1-1/2" Grade 8, Hex Head Bolt ............................................................................................Legs
5/8" (1.5875 cm) x 2-3/4" Grade 8, Hex Head Bolt .............................................................. Base Stiffeners to Legs
5/8" (1.5875 cm) x 2" (5.08 cm) Grade 8, Hex Head Bolt .........................................................................Leg to Leg
5/8" (1.5875 cm), Grade 5-1, Hex Head Nut.............................................................................................Leg to Leg
3/4" (1.905 cm) Washer (1-1/2" diameter) .........................................................................................................Legs
3/4" (1.905 cm) Hex Head Nut .......................................................................................................................X-Rods
3/4" (1.905 cm) Washer (2" diameter) ...........................................................................................................X-Rods
Stainless Steel
5/16" (0.79375 cm) x 3/4" (1.905 cm) Whiz Lock Bolt .............................................................. Outside Wall Sheets
5/16" (0.79375 cm) x 1" (2.54 cm) Whiz Lock Bolt .................................................................. Outside Wall Sheets
5/16" (0.79375 cm) Whiz Lock Nut ........................................................................................... Outside Wall Sheets
Miscellaneous
Anchor Bolt, HILTI HAS, 3/4" (1.905 cm) x 9-5/8" .............................................................................................Legs
Anchor Bolt, Heavy Duty Expanding, 1/2" (1.27 cm) x 3-3/4" ................................................................Control Box
De Sta Co Clamp .......................................................................................................................Hopper Access Port
