Grain Systems PNEG-1590 - Manual

Revision 08
Page 1 of 3
PNEG-1590
Dryer Final Assembly & Testing Checklist
Customer Name: _____________________________________________________________________________________
Order #: __________________________________________ Serial #: ______________________ MET#: _____________
Model #: ___________________________________________ Date: ___________________________________________
Basket Assembly Checklist
___ ___ Check Order for all Dryer Options
___ ___ Check for loose bolts on dryer (Hit screens and panels and listen for rattles).
___ ___ Check that all screens installed with rough side out.
___ ___ Make sure Plenum Sensor located 36” from rear of Dryer.
___ ___ Check Wet Bin Tie Downs are installed.
___ ___ Check Hair Pins & Wedges are installed.
___ ___ Check that the plastic grommets are installed on the EMT conduit running to the back of the dryer.
___ ___ Check that all lock collars have been installed and the correct rotation applied.
___ ___ Blow off all metal filings from front and rear mounting angles.
___ ___ Check that bottom belt guard is installed correctly and motors are not pushing guards out.
___ ___ Check bottoms of control boxes for foreign material and blow out both if necessary.
___ ___ Check that both doors close without binding and will seal properly (Check weather seal on both doors for contact).
___ ___ Ground cable installed between both door and control box.
___ ___ Check that safety disconnect works properly.
___ ___ Check that hole plugs have been installed and siliconed.
___ ___ Ground lug installed.
___ ___ Check for loose connections by pulling on all control wires and tighten all power wires.
___ ___ Check that each wire has a label in both control boxes.
___ ___ Check and tighten all conduit fittings. Check upper junction box is siliconed.
___ ___ Put weep holes in bottom of white boxes.
___ ___ Make sure burner is centered
___ ___ Make sure grain hi-limits 210 are in grain column & plenum high limits 300 are in plenum
Review Paint Checklist
___ ___ Hand hold rail and grab bar.
___ ___ Shaft ends painted on Motors, Meter rolls, Augers
___ ___ Lock collars painted aluminum.
___ ___ Teflon sprayed on load motor shaft.
___ ___ Hitch
___ ___ Fan Heater blades have aluminum centers painted black for GSI / Aluminum for FFI.
___ ___ Venturi(s) & Grille Guards
___ ___ Pipe train painted black and touch up if necessary.
___ ___ All writing on metal removed.
Review Decal packing list to ensure all decals are on the dryer
___ ___ Two GSI “footballs” on frame (GSI).
___ ___ “Confined Space” decal on rear door (FFI).
___ ___ Auger warning on both sides of rear plenum closure door (GSI/FFI).
___ ___ Auger warning on both sides of access panel, front and rear (GSI).
___ ___ Auger warning on grain discharge. (1 inside and out) (GSI/FFI).
___ ___ Fire danger on rear access door. (1 inside and out) (GSI/FFI).
___ ___ Belt and chain warnings on inside of belt guard (GSI/FFI).
___ ___ Pulley guard has belt and chain warnings installed.
___ ___ Airswitch adjustment decal.
___ ___ Competitor flag installed (2000 series only).
___ ___ GSI decal installed on fan support panel (2000 series only).
___ ___ Error decal inside MCB (2000 series only)
___ ___ Electrical hazard warning installed on fan can lid.
___ ___ Electrical hazard warning beside fan can control box.
___ ___ Warning on meter roll access door (Each Door).
___ ___ Electrical warning decal on Network Fan/Heater box
___ ___ Model # (Single fan, above can in front and above door in rear) (2 fan, below bottom of fan on front panel).
