24. Fuel Train
252
PNEG-707 12', 18', 24' and 30' GSI Commercial Tower Dryer
Figure 24U Maxons (A) and modutrol mounting
bracket (B) installed. Support fuel train at all times.
Figure 24V Installing regulator section.
Figure 24W Checking fuel train is level, then
measuring for fuel train stands.
Figure 24X Adapt fuel train stands to meet
site requirements.
Figure 24Y Close Up - Bolting fuel train stand.
Figure 24Z Securing fuel train to fuel train stand
with 3" U-bolt.
A
A
B
