GS-4012F/4024 User’s Guide
Chapter 46 IEEE 802.1Q Tagged VLAN Commands 319
C
H A P T E R
46
IEEE 802.1Q Tagged VLAN
Commands
This chapter describes the IEEE 802.1Q Tagged VLAN and associated commands.
46.1 Configuring Tagged VLAN
The following procedure shows you how to configure tagged VLAN.
1 Use the IEEE 802.1Q tagged VLAN commands to configure tagged VLAN for the
switch.
• Use the vlan command to configure or create a VLAN on the switch. The
switch automatically enters the config-vlan mode.Use the inactive command to
deactivate the VLAN(s).
• Use the interface port-channel command to enter the config-
interface mode to set the VLAN settings on a port, then use the pvid
command to set the VLAN ID you created for the port-list to that specific port in the
PVID table.
• Use the exit command when you are finished configuring the VLAN.
2 Configure your management VLAN.
• Use the vlan command to create a VLAN (VID 3 in this example) for
managing the switch, and the switch will activate the new management VLAN.
• Use the inactive command to disable the new management VLAN.
sysname (config)# vlan 2000
sysname (config-vlan)# name up1
sysname (config-vlan)# fixed 5-8
sysname (config-vlan)# no untagged 5-8
sysname (config-vlan)# exit
sysname (config)# interface port-channel 5-8
sysname (config-interface)# pvid 2000
sysname (config-interface)# exit
sysname (config)# vlan 3
sysname (config-vlan)# inactive
