GS-4012F/4024 User’s Guide
254 Chapter 42 Introducing Commands
42.2.1.1 Initial Screen
When you turn on your switch, it performs several internal tests as well as line initialization.
You can view the initialization information using the console port. After the initialization, the
login screen displays (refer to
Section 42.3 on page 254 ).
Use the following steps to telnet into your switch.
1 For local management, connect your computer to the RJ-45 management port (labeled
MGMT) on the switch.
2 Make sure your computer IP address and the switch IP address are on the same subnet. In
Windows, click Start (usually in the bottom left corner), Run and then type telnet
192.168.0.1 (the default management IP address) and click OK.
3 A login screen displays (refer to Section 42.3 on page 254 ).
42.3 The Login Screen
After you have successfully established a connection to the switch using a direct console
connection or Telnet, a login screen displays as shown below. For your first login, enter the
default administrator login username “admin” and password “1234”.
42.4 Command Syntax Conventions
The rules of the commands are listed next.
• The command keywords are in courier new font .
• The required fields in a command are enclosed in angle brackets <>, for instance, ping
means that you must specify an IP number for this command.
• The optional fields in a command are enclosed in square brackets [], for instance,
configure snmp-server [contact ] [location location>]
Copyright (c) 1994 - 2006 ZyXEL Communications Corp.
initialize mgmt, ethernet address: 00:13:49:00:00:01
initialize switch, ethernet address: 00:13:49:00:00:02
Initializing switch unit 0...
Initializing VLAN Database...
Initializing IP Interface...
Initializing Advanced Applications...
Initializing Command Line Interface...
Initializing Web Interface...
Press ENTER to continue...
Enter User Name : admin
Enter Password : XXXX
