GS-4012F/4024 User’s Guide
204 Chapter 31 VRRP
Figure 109 VRRP Configuration: VRRP Parameters
The following table describes the labels in this screen.
31.4 VRRP Configuration Summary
To view a summary of all VRRP configurations on the switch, scroll down to the bottom of
the VRRP Configuration screen.
Table 79 VRRP Configuration: VRRP Parameters
LABEL DESCRIPTION
Active Select this option to enable this VRRP entry.
Name Enter a descriptive name (up to 32 printable ASCII characters) for identification
purposes.
Network Select an IP domain to which this VRRP entry applies.
Virtual Router ID Select a virtual router number (1 to 7) for which this VRRP entry is created.
You can configure up to seven virtual routers for one network.
Advertisement Interval Specify the number of seconds between Hello message transmissions.
Preempt Mode Select this option to activate preempt mode.
Priority Enter a number (between 1 and 254) to set the priority level. The bigger the
number, the higher the priority.
Uplink Gateway Enter the IP address of the uplink gateway in dotted decimal notation.
The switch checks the link to the uplink gateway.
Primary Virtual IP Enter the IP address of the primary virtual router in dotted decimal notation.
Secondary Virtual IP This field is optional. Enter the IP address of a secondary virtual router in
dotted decimal notation. This field is ignored when you enter 0.0.0.0.
Add Click Add to save your changes to the switch’s run-time memory. The switch
loses these changes if it is turned off or loses power, so use the Save link on
the top navigation panel to save your changes to the non-volatile memory when
you are done configuring.
Cancel Click Cancel to discard all changes made in this table.
Clear Click Clear to set the above fields back to the factory defaults.
