SETTING UP PRINT JOB SOURCES
2. Hold the cartridge with the smooth side on top and the
leader block toward the drive.
3. Insert the cartridge into the entry slot and slide it all the way
into the drive opening until it stops.
CAUTION: When you insert a cartridge, never force it.
Loading and unloading a floppy diskette from the system controller
Follow these steps to load and unload a floppy diskette:
1. Before inserting a floppy diskette into the floppy diskette
drive, make sure the lever is in the open (horizontal)
position. Insert the floppy diskette, label side up, until the
jacket is solidly against the stops. Move the lever clockwise
to the closed (vertical) position.
1 Lever
2 Floppy diskette drive
3 Floppy diskette
3-4 XEROX 4050/4090/4450/4650 LPS OPERATOR GUIDE
