SOLVING PROBLEMS
Follow these steps to clear area 6A of the high-capacity feeder
(HCF):
1. Open the top cover of the HCF. (Also open the top cover
of the stacker, if the printer control console message display
indicates it needs to be opened.)
2. Remove and discard any sheets under the HCF cover.
If the printer control console message display also indicates a
problem in the output module, remove and discard those
sheets as well. Refer to the appropriate “Areas” section of
this chapter for detailed instructions.
Clearing area 7
Area 7 of the paper path is used only during two-sided (duplex)
printing. Follow these steps to clear area 7:
1. Pull the block-shaped set separator toward you and hold it in
that position.
2. Remove and discard any paper in the duplex tray or
beginning to feed from it.
3. Return the set separator to its upright position.
XEROX 4050/4090/4450/4650 LPS OPERATOR GUIDE 8-11
