SOLVING PROBLEMS
2. Pull the green handle down and to the left (in the direction
of the arrow marked on it) to hold the assembly open.
3. Remove any paper.
Clearing areas A and B
Follow these steps to clear area A of the stitcher/stacker:
1. Open the top cover of the stitcher/stacker and locate area A
in the center.
2. The instruction label for area A indicates that you should
remove only the paper under this paper guide.
The paper guide is a spring-loaded, heavy wire form guide
that pops up when you open the cover.
3. Remove and discard any paper found in this area.
Follow these steps to clear area B of the stitcher/stacker:
1. Open the top cover of the stitcher/stacker and locate the
side cover of area B on the right.
XEROX 4050/4090/4450/4650 LPS OPERATOR GUIDE 8-13
