I n t e r f a c e M e n u
C h a p t e r 3 : U s i n g t h e C o n t r o l P a n e l ❖ 3-51
The Ethernet Menu , a submenu of the Interface Menu,
Figure 3.13 (page 3-38) , contains options for configuring the
printer’s Ethernet port, when the Ethernet option has been
installed .
The Ethernet option supports the following protocols:
• Novell NetWare, Version 3.11
• TCP/IP
• EtherTalk
• DEC LAT
• Microsoft LAN Manager
For detailed information on the supported protocols, refer to
Networking: Ethernet packaged with the Ethernet option kit.
Figure 3.17 describes each Ethernet Menu option. Factory
settings are boldfaced and followed by an asterisk ( * ). See
“Setting a Menu Option” (page 3-10) for the steps to find and
change a setting, or refer to the Document Services for
Printing Guide to use the RUI to change settings.
Figure 3.17 Ethernet Menu options showing factory settings
Option Setting Description
Port Timeout 5-999 secs ( 30* ) Time interval for determining when to end an
incomplete print job and poll the next port in the
polling sequence.
Port Timeout works in conjunction with Auto Job
End (page 3-53).
See Appendix C: I/O Port Polling for more information
on how port polling works.
System Language PCL*
PostScript
†
† Appears only when the
PostScript option is
installed.
Page description language (PDL) the printer will use
for print jobs coming through the Ethernet port.
When Lang. Sensing (page 3-52) is On , System
Language is used only when the printer cannot
detect the PDL used in the incoming print job.
Ethernet Menu
Options
