P C L P r i n t e r C o m m a n d s
A p p e n d i x B : P r i n t e r C o m m a n d s ( E s c a p e S e q u e n c e s ) ❖ B-3
PCL printer commands—also called escape sequences —are
used by software applications to control how fonts and
graphics are printed on the page . Figure B.1 lists the PCL
printer commands for the 4505/4505ps and 4510/4510ps
printers.
Figure B.1 PCL printer commands
Function Parameter Command Decimal Value Hexadecimal Value
JOB CONTROL COMMANDS
Reset
Universal Exit
Language (ULE) — E
C
%-12345X 027 037 045 049 050
051 052 053 088 1B 25 2D 31 32 33 34 35
58
Reset — E
C
E 027 069 1B 45
Number Of
Copies # of Copies E
C
&l#X 027 038 108 # ... # 088 1B 26 6C # ... # 58
Long Edge (Left)
Offset
Registration # of Decipoints
(1/720”)
E
C
&l#U 027 038 108 # ... # 085 1B 26 6C # ... # 55
Short Edge
(Top) Offset
Registration # of Decipoints
(1/720”) E
C
&l#Z 027 038 108 # ... # 090 1B 26 6C # ... # 5A
Unit Of
Measure # = Number of
units per inch
E
C
&u#D 027 038 117 # ... # 068 1B 26 75 # ... # 44
PAGE CONTROL COMMANDS
Page Length and Size
Paper Source Eject Page E
C
&l0H 027 038 108 048 072 1B 26 6C 30 48
Main Paper
Source (Standard)
E
C
&l1H 027 038 108 049 072 1B 26 6C 31 48
Manual Feed (MP) E
C
&l2H 027 038 108 050 072 1B 26 6C 32 48
Manual Envelope
Feed (MP) E
C
&l3H 027 038 108 051 072 1B 26 6C 33 48
Alternate Paper
Source (Lower)
E
C
&l4H 027 038 108 052 072 1B 26 6C 34 48
PCL Printer
Commands
