P r i n t Q u a l i t y P r o b l e m s
C h a p t e r 7 : T r o u b l e s h o o t i n g ❖ 7-31
Vertical line deletions
Localized print deletions
forming narrow lines
running in the direction
of paper movement.
1. Defective EP cartridge
2. Defective paper stock,
creases, folds, etc.
3. Contaminated Bias Transfer
Roll
1. Replace EP cartridge.
2. Replace paper stock.
3. Contact your dealer or Xerox / Rank
Xerox.
Horizontal line
deletions
Localized print deletions
appearing as bands
running across the page
perpendicular to the
direction of paper
movement.
1. Defective EP cartridge
2. Defective paper stock,
creases, folds, etc.
3. Contaminated Bias Transfer
Roll
1. Replace EP cartridge.
2. Replace paper stock.
3. Contact your dealer or Xerox / Rank
Xerox.
Figure 7.5 Print Quality Problems (continued)
Problem Possible Causes Corrective Actions
