P C L P r i n t e r C o m m a n d s
B-14 ❖ 4 5 0 5 / 4 5 0 5 p s o r 4 5 1 0 / 4 5 1 0 p s U s e r ’ s G u i d e
GRAPHICS
Raster Graphics
Raster
Resolution 75 dots/inch E
C
*t75R 027 042 116 055 053
082 1B 2A 74 37 35 52
100 dots/inch E
C
*t100R 027 042 116 049 048
048 082 1B 2A 74 31 30 30 52
150 dots/inch E
C
*t150R 027 042 116 049 053
048 082 1B 2A 74 31 35 30 52
200 dots/inch E
C
*t200R 027 042 116 050 048
048 082 1B 2A 74 32 30 30 52
300 dots/inch E
C
*t300R 027 042 116 051 048
048 082 1B 2A 74 33 30 30 52
600 dots/inch E
C
*t600R 027 042 116 054 048
048 082 1B 2A 74 36 30 30 52
Raster Graphics
Presentation Follows
orientation E
C
*r0F 027 042 114 048 070 1B 2A 72 30 46
Follows physical
page E
C
*r3F 027 042 114 051 070 1B 2A 72 33 46
Start Raster
Graphics Left Raster
Graphics Margin
E
C
*r0A 027 042 114 048 065 1B 2A 72 30 41
Current Cursor E
C
*r1A 027 042 114 049 065 1B 2A 72 31 41
Raster Y Offset # of Raster Lines
of vertical
movement E
C
*b#Y 027 042 098 # ... # 089 1B 2A 62 # ... # 59
Set Raster
Compression
Mode (Method) Unencoded E
C
*b0M 027 042 098 048 077 1B 2A 62 30 4D
Run-Length
Encoded E
C
*b1M 027 042 098 049 077 1B 2A 62 31 4D
Tagged Image File
Format E
C
*b2M 027 042 098 050 077 1B 2A 62 32 4D
Delta Row E
C
*b3M 027 042 098 051 077 1B 2A 62 33 4D
Figure B.1 PCL printer commands (continued)
