D i s p l a y e d C o n t r o l P a n e l M e s s a g e s
C h a p t e r 7 : T r o u b l e s h o o t i n g ❖ 7-7
Config. Sheet
Printing... The Configuration Sheet is printing.
See Config. Sheet , page 3-62.
ACTION: None
Ethernet Fail The Ethernet card (XNIC-E’NET) has failed and cannot be used.
ACTION: Press Enter to allow the printer to continue as if the Ethernet card
were not installed. This error is not subject to Auto Continue (page 3-59). Print a
Configuration Sheet. If the sheet does not show Ethernet as present, contact your
dealer or Xerox / Rank Xerox.
Flushing… For PostScript only, the print job could not be printed and is being parsed out and
discarded.
ACTION: The message remains until the print job being flushed is complete, which
may require further data to be sent from the host.
Fuser Cleaning
Please Wait... The Fuser Cleaning (page 3-64) function has been selected from the Test Menu.
This message appears when the three cleaning sheets have been printed, placed in
the input tray, and are now being fed into the printer.
ACTION: None
Fuser Cleaning
Printing... The Fuser Cleaning (page 3-64) function has been selected from the Test Menu.
The three cleaning sheets are being printed.
ACTION: None
Fuser Cleaning
Waiting... The Fuser Cleaning (page 3-64) function has been selected from the Test Menu.
The cleaning sheets have been printed.
ACTION: Place the three cleaning sheets, printed side down and arrow toward
printer, in the standard paper tray. Press
Enter
Fuser Failure
Service Required Fuser assembly has failed; printing cannot resume.
ACTION: Contact your dealer or Xerox / Rank Xerox.
Hex Dump Hex dump mode is On .
Used for debugging. See Hex Dump (page 3-58).
ACTION: None
Figure 7.2 Control Panel messages (continued)
Message Description/Action
