C o n t r o l P a n e l F e a t u r e s
C h a p t e r 3 : U s i n g t h e C o n t r o l P a n e l ❖ 3-5
Shown in Figure 3.3, three indicator lights—also called LEDs
for light-emitting diodes—show the activity status of the
printer.
Figure 3.3 Indicator lights
Figure 3.4 describes the function of each indicator light.
Figure 3.4 Indicator light functions
Indicator Description
Online The light is on when the printer is warmed up and available for printing.
The light goes off when:
• You press Online to take the printer offline.
• There is a failure or operation that makes the printer unavailable.
Form Feed The light comes on when a partial page has been prepared for printing, rather than an
entire page.
To eject the partial page, press Form Feed when the printer is offline.
See Figure 3.5 (page 3-6) for information on the Form Feed key.
Ready The light comes on when the printer is powered ON and remains lit unless a failure makes
the printer unavailable.
The Ready light flashes to indicate that the printer is receiving data to print.
The Indicator
Lights
O n l i n e _ _ _
R e a d y
Online Form Feed Ready
