Printer components – Xerox 4505/4505ps User Manual
Page 9
O v e r v i e w
C h a p t e r 1 : I n t r o d u c t i o n
❖
1-3
The key printer components are called out in Figure 1.1.
Figure 1.1
Key printer components
Printer
Components
Font Card Slots
Power Switch
Output Tray
Control Panel
Multipurpose (MP)
Paper Source
Front Cover
250-sheet Paper Tray
Network Port 1
Network Ports 2 & 3
(4510/4510ps only)
Serial Port
Parallel Port
Power Inlet
AUG-CH01 Page 3 Black,Red,Cyan Saturday, January 21, 1995 6:00 PM
