S e l e c t i n g a P a p e r S o u r c e
C h a p t e r 2 : H a n d l i n g P a p e r ❖ 2-25
For each of the six PCL paper sources listed in Figure 2.10
(page 2-22) , a Source Mapping setting from Figure 2.11 is
used. You may change settings depending on your printing
needs. For details, see “Factory Source Mapping Settings”
(page 2-26) , “Source Mapping Examples” (page 2-27) , and
Source Mapping (page 3-22).
† Use sequences starting with MP to print the first pages of a print job on special
paper stock by placing the required number of special stock sheets in the MP tray
(page 2-11).
Figure 2.11 Source Mapping settings
Source Mapping
setting
Description
Standard
MP Tray
Standard-MP
MP-Standard
†
Tray or tray sequence to be used for each
of the six PCL paper sources.
Lower
Standard-Lower
Lower-Standard
Lower-MP
Std-Low-MP
Low-Std-MP
MP-Lower
†
MP-Std-Low †
MP-Low-Std
†
Additional settings that appear only
when a lower base (page 2-13) is
installed.
Source Mapping
Settings
