D i s p l a y e d C o n t r o l P a n e l M e s s a g e s
7-14 ❖ 4 5 0 5 / 4 5 0 5 p s o r 4 5 1 0 / 4 5 1 0 p s U s e r ’ s G u i d e
Std. Tray Empty The standard tray does not contain paper.
ACTION: Add paper to the standard tray.
Std. Tray Out The standard tray has been removed or is not properly inserted.
ACTION: Insert the standard tray.
Temp Font/Macro The printer was busy processing PCL data from a host system but the job was not
completed since temporary fonts and macros were not deleted. The last page
timeout has expired.
This message appears until:
• Another print job is received.
• The Port Timeout expires and Auto Job End is On . See Chapter 3: Using the
Control Panel , “Interface Menu” (page 3-37) .
ACTION: None
Test Print
Printing... A Test Print is being printed (for use by service technicians).
The message clears once the printing is completed.
ACTION: None
Token Ring Fail The Token Ring card (XNIC-T’RING) has failed and cannot be used.
ACTION: Press Enter to allow the printer to continue as if the Token Ring
card were not installed. This error is not subject to Auto Continue (page 3-59).
Print a Configuration Sheet. If the sheet does not show Token Ring as present,
contact your dealer or Xerox / Rank Xerox.
Toner Low Toner is getting low in the EP cartridge, but printing will continue without
interruption.
ACTION: Replace the EP cartridge as soon as possible.
Turn Power Off
Then On A fatal error has occurred.
ACTION: Power OFF [0], then ON [1].
Upper Card Err
Power Off & On Upper font card was removed while the printer was online.
ACTION: Power OFF [0] the printer, then power it ON [1] to resume normal
operations.
Figure 7.2 Control Panel messages (continued)
Message Description/Action
