P r i n t Q u a l i t y P r o b l e m s
7-36 ❖ 4 5 0 5 / 4 5 0 5 p s o r 4 5 1 0 / 4 5 1 0 p s U s e r ’ s G u i d e
TrueRes Smoothing
problems
TrueRes Smoothing is a
technology that smooths
the jagged edges of
curved or near
vertical/horizontal lines.
Produce Test Prints (see
Chapter 3 ) with TrueRes
switched both ON and
OFF. Inspect the TrueRes
target on the Test Print.
If:
1. TrueRes is not
functional (no
apparent difference
between ON and
OFF setting)
2. TrueRes appears
excessively dark:
or
TrueRes appears
insufficient
1. Failed Controller.
2. Print Density set to dark/light.
1. Replace Controller.
Contact your dealer or Xerox / Rank
Xerox.
2. Adjust Print Density (see Chapter 6 ).
Figure 7.5 Print Quality Problems (continued)
Problem Possible Causes Corrective Actions
