P C L P r i n t e r C o m m a n d s
A p p e n d i x B : P r i n t e r C o m m a n d s ( E s c a p e S e q u e n c e s ) ❖ B-15
Adaptive
compression
E
C
*b5M 027 042 098 053 077 1B 2A 62 35 4D
Transfer Raster
Data by row # of Bytes E
C
*b#W[Data
]
027 042 098 # ... # 087 1B 2A 62 # ... # 57
End Raster
Graphics Old version
E
C
*rB 027 042 114 066 1B 2A 72 42
preferred E
C
*rC 027 042 114 067 1B 2A 72 43
Raster Height # Raster Rows E
C
*r#T 027 042 114 # ... # 084 1B 2A 72 # ... # 54
Raster Width # Pixels of the
Specified
Resolution E
C
*r#S 027 042 114 # ... # 083 1B 2A 72 # ... # 53
THE PRINT MODEL
Imaging
Select Current
Pattern Solid Black
(default) E
C
*v0T 027 042 118 048 084 1B 2A 76 30 54
Solid White
E
C
*v1T 027 042 118 049 084 1B 2A 76 31 54
HP-defined
Shading Pattern E
C
*v2T 027 042 118 050 084 1B 2A 76 32 54
HP-defined
Cross-Hatched
Pattern
E
C
*v3T 027 042 118 051 084 1B 2A 76 33 54
User-defined
pattern E
C
*v4T 027 042 118 052 084 1B 2A 76 34 54
Source
Transparency
Mode Transparent
E
C
*v0N 027 042 118 048 078 1B 2A 76 30 4E
Opaque E
C
*v1N 027 042 118 049 078 1B 2A 76 31 4E
Pattern
Transparency
Mode Transparent E
C
*v0O 027 042 118 048 079 1B 2A 76 30 4F
Opaque
E
C
*v1O 027 042 118 049 079 1B 2A 76 31 4F
Figure B.1 PCL printer commands (continued)
Function Parameter Command Decimal Value Hexadecimal Value
