Chapter 2 Introducing the Web Configurator
P-660HWP-Dx User’s Guide
42
The following table describes the labels shown in the Status screen.
Table 4 Status Screen
LABEL DESCRIPTION
Refresh Interval Select a number of seconds or None from the drop-down list box to refresh all
screen statistics automatically at the end of every time interval or to not refresh the
screen statistics.
Apply Click this button to refresh the status screen statistics.
Device Information
Host Name This is the System Name you enter in the Maintenance > System > General
screen. It is for identification purposes.
Model Number This is your P-660HWP-Dx’s model name.
MAC Address This is the MAC (Media Access Control) or Ethernet address unique to your P-
660HWP-Dx.
ZyNOS Firmware
Version
This is the ZyNOS firmware version and the date created. ZyNOS is ZyXEL's
proprietary Network Operating System design.
DSL Firmware
Version
This is the DSL firmware version associated with your P-660HWP-Dx. This is
sometimes needed by technicians to help troubleshoot problems.
WAN Information
DSL Mode This is the standard that your P-660HWP-Dx is using.
IP Address This is the WAN port IP address.
IP Subnet Mask This is the WAN port IP subnet mask.
Default Gateway This is the IP address of the default gateway, if applicable.
VPI/VCI This is the Virtual Path Identifier and Virtual Channel Identifier that you entered in
the wizard or WAN screen.
LAN Information
IP Address This is the LAN port IP address.
IP Subnet Mask This is the LAN port IP subnet mask.
DHCP This is the WAN port DHCP role - Server, Relay or None.
WLAN Information (Wireless devices only)
SSID This is the descriptive name used to identify the P-660HWP-Dx in the wireless
LAN.
Channel This is the channel number used by the P-660HWP-Dx now.
Security This displays the level of wireless security the P-660HWP-Dx is using.
Security
Firewall This displays whether or not the P-660HWP-Dx’s firewall is activated.
Content Filter This displays whether or not the P-660HWP-Dx’s content filtering is activated.
System Status
System Uptime This is the total time the P-660HWP-Dx has been on.
Current Date/
Time
This field displays your P-660HWP-Dx’s present date and time.
System Mode This displays whether the P-660HWP-Dx is functioning as a router or a bridge.
