Chapter 7 Wireless LAN
P-660HWP-Dx User’s Guide
56
Click Network > Wireless LAN > QoS. The following screen displays.
Figure 76 Wireless LAN: QoS
The following table describes the fields in this screen.
Table 42 Wireless Lan: QoS
LABEL DESCRIPTION
QoS
Enable WMM QoS Select the check box to enable WMM QoS on the P-660HWP-Dx.
WMM QoS Policy Select Default to have the P-660HWP-Dx automatically give a service a
priority level according to the ToS value in the IP header of packets it sends.
Select Application Priority from the drop-down list box to display a table of
application names, services, ports and priorities to which you want to apply
WMM QoS.
# This is the number of an individual application entry.
Name This field displays a description given to an application entry.
Service This field displays either FTP, WWW, E-mail or a User Defined service to
which you want to apply WMM QoS.
Dest Port This field displays the destination port number to which the application sends
traffic.
Priority This field displays the WMM QoS priority for traffic bandwidth.
Modify Click the to open the Application Priority Configuration screen. Modify an
existing application entry or create a application entry in the Application
Priority Configuration screen.
Click the Remove icon to delete an application entry.
Apply Click Apply to save your changes back to the P-660HWP-Dx.
Cancel Click Cancel to reload the previous configuration for this screen.
