P-660HWP-Dx User’s Guide
35
A
P P E N D I X
A
Product Specifications and Wall
Mounting
Product Specifications
The following tables summarize the P-660HWP-Dx’s hardware and firmware features.M4
Table 135 Hardware Specifications
Dimensions (W x D x H) 250 x 170 x 36 mm
Power Specification Input: 100~240 V AC, 50-60 Hz
Output: 12V AC 1A
Built-in Switch Four auto-negotiating, auto MDI/MDI-X 10/100 Mbps RJ-45 Ethernet ports
Operation Temperature 0º C ~ 40º C
Storage Temperature -20º ~ 60º C
Operation Humidity 20% ~ 85% RH
Storage Humidity 10% ~ 90% RH
Distance between the
centers of the holes (for
wall mounting) on the
device’s back.
215.5 mm
Screw size for wall-
mounting
M4 Tap Screw
Antenna The P-660HWP-Dx is equipped with one 3dBi detachable antenna.
Table 136 Firmware Specifications
FEATURE DESCRIPTION
Default IP Address 192.168.1.1
Default Subnet Mask 255.255.255.0 (24 bits)
Default Admin Password 1234
Default User Password user
DHCP Pool 192.168.1.33 to 192.168.1.64
Device Management Use the web configurator to easily configure the rich range of features on
the P-660HWP-Dx.
