Chapter 7 Wireless LAN
P-660HWP-Dx User’s Guide
57
7.8.2 Application Priority Configuration
To edit a WMM QoS application entry, click the edit icon ( ) under Modify. The following
screen displays.
Figure 77 Application Priority Configuration
The following table describes the fields in this screen.
Table 43 Application Priority Configuration
LABEL DESCRIPTION
Application Priority Configuration
Name Type a description of the application priority.
Service The following is a description of the applications you can prioritize with WMM
QoS. Select a service from the drop-down list box.
•
FTP
File Transfer Program enables fast transfer of files, including large files that
may not be possible by e-mail. FTP uses port number 21.
•
E-Mail
Electronic mail consists of messages sent through a computer network to
specific groups or individuals. Here are some default ports for e-mail:
POP3 - port 110
IMAP - port 143
SMTP - port 25
HTTP - port 80
•
WWW
The World Wide Web is an Internet system to distribute graphical, hyper-linked
information, based on Hyper Text Transfer Protocol (HTTP) - a client/server
protocol for the World Wide Web. The Web is not synonymous with the
Internet; rather, it is just one service on the Internet. Other services on the
Internet include Internet Relay Chat and Newsgroups. The Web is accessed
through use of a browser.
•
User-Defined
User-defined services are user specific services configured using known ports
and applications.
Dest Port This displays the port the selected service uses. Type a port number in the
field provided if you want to use a different port to the default port. See table
Table 41 on page 53 for information on port numbers.
Priority Select a priority from the drop-down list box.
