Appendix A Product Specifications and Wall Mounting
P-660HWP-Dx User’s Guide
39
Wall-mounting Instructions
Complete the following steps to hang your P-660HWP-Dx on a wall.
"
See the Hardware Specifications table for the size of screws to use and how far
apart to place them.
1 Select a high position on a sturdy wall that is free of obstructions.
2 Drill two holes for the screws.
3 Be careful to avoid damaging pipes or cables located inside the wall when drilling holes
for the screws.
4 Do not insert the screws all the way into the wall. Leave a small gap of about 0.5 cm
between the heads of the screws and the wall.
5 Make sure the screws are snugly fastened to the wall. They need to hold the weight of
the P-660HWP-Dx with the connection cables.
6 Align the holes on the back of the P-660HWP-Dx with the screws on the wall. Hang the
P-660HWP-Dx on the screws.
IEEE 802.1x Port Based Network Access Control.
ANSI T1.413, Issue 2 Asymmetric Digital Subscriber Line (ADSL) standard.
G dmt(G.992.1) G.992.1 Asymmetrical Digital Subscriber Line (ADSL) Transceivers
ITU G.992.1 (G.DMT) ITU standard for ADSL using discrete multitone modulation.
ITU G.992.3 (G.dmt.bis) ITU standard (also referred to as ADSL2) that extends the capability of
basic ADSL in data rates.
ITU G.992.5 (ADSL2+) ITU standard (also referred to as ADSL2+) that extends the capability of
basic ADSL by doubling the number of downstream bits.
Microsoft PPTP MS PPTP (Microsoft's implementation of Point to Point Tunneling
Protocol)
MBM v2 Media Bandwidth Management v2
RFC 2383 ST2+ over ATM Protocol Specification - UNI 3.1 Version
TR-069 TR-069 DSL Forum Standard for CPE Wan Management.
1.363.5 Compliant AAL5 SAR (Segmentation And Re-assembly)
Table 138 Standards Supported (continued)
STANDARD DESCRIPTION
