iTherm ® 280 Programmer’s Guide Programming Codes
28-07764 Rev C Page 223
Mechanism Control Commands
Function Select cut mode and cut paper
ASCII [GS] V
Hexadecimal 1DH 56H
Decimal
<29> <86>
Description When = 1 or 49, is not used and a partial cut is performed. When
= 66, [GS] V executes a partial cut (one point left uncut) after paper is
fed [cutting position ( x approximately 1/144 inch)]. When using the
command, there is a gap between the auto-cutter position and the print position.
The [GS] V command is only effective when input at the beginning of a
line. The [GS] V command executes paper feeding to the manual
cutting position.
Function Partial knife cut
ASCII [ESC] i
Hexadecimal 1BH 69H
Decimal
<27> <105>
Description The [ESC] i command performs a partial knife cut.
Function Perform a partial knife cut
ASCII [ESC] m
Hexadecimal 1BH 6DH
Decimal
<27> <109>
Description The [ESC] m command performs a partial knife cut.
Function Sound buzzer
ASCII [BEL]
Hexadecimal 07H
Decimal
<07>
Description The [BEL] command sounds the internal buzzer, if equipped.
Function Sound buzzer
ASCII [ESC] BEL
Hexadecimal 1BH 07H
Decimal
<27> <07>
Description The [ESC] BEL command sounds the internal buzzer, if equipped.
