iTherm
®
280 Programmer’s Guide
Programming Codes
28-07764
Rev C
Page 215
0
Off
00H
<0>
Pin 3 is Low
On
(03H)
(3)
Pin 3 is High
1 – 7
Off
00H
<0>
Not used; fixed to Off
Table 40 Peripheral Status (
Function
Transmit Paper Sensor Status
ASCII
[ESC] v
Hexadecimal 1BH 76H
Decimal
<27> <118>
Description The [ESC] v command has been replaced by the [GS] r command. The [ESC] v
command transmits paper status has been replaced by the [GS] r command.
The iTherm
®
280 return paper status as specified below. If the Electronic Journal
is enabled, Journal Low and Out are supported by this command
Electronic Journal Disabled
Bit
Off/On
Hex
Decimal
Status
0,1
Off
00
<0>
Receipt Paper present
On
02H
<2>
Receipt Paper Low or not present
2,3
Off
00
<0>
Cover is closed
On
04H
<4>
Cover is open
4
Off
00
<0>
Not used, fixed Off
5
Off
00
<0>
Slip is present
On
04H
<4>
Slip is not present
6
ON
20H
<64>
Fixed On
7
Off
00
<0>
Not used, fixed Off
Electronic Journal Enabled
Bit
Off/On
Hex
Decimal
Status
0
Off
00H
<0>
Journal Space adequate > 8K
On
01H
<1>
Journal Space Low < 8K
1
Off
00
<0>
Receipt Paper present
On
02H
<2>
Receipt Paper Low or not present
2
Off
00
<0>
Cover is closed
On
04H
<4>
Cover is open
3
Off
00
<0>
Journal is active and not full (Cover
Closed)
On
08H
<8>
Journal Full and has been disabled (or
Cover Open)
4
Off
00
<0>
Not used, fixed Off
5
Off
00
<0>
Slip is present
On
04H
<4>
Slip is not present
6
ON
20H
<64>
Fixed On
7
Off
00
<0>
Not used, fixed Off
Table 41 Paper Status
